Hi, Friends today I am going to share code by which you can use android camera 2 api to click picture. I’d created two classes named as CameraControllerV2WithPreview for taking picture with preview and another one is CameraControllerV2WithoutPreview for taking picture without preview. Camera 2 Api is latest Api introduced in android version Lollipop, So Camera 2 Api can be used in Lollipop and higher versions of android.
So here is the code,
CameraControllerV2WithPreview.java
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 332 333 334 335 336 337 338 339 340 341 342 343 344 345 346 347 348 349 350 351 352 353 354 355 356 357 358 359 360 361 362 363 364 365 366 367 368 369 370 371 372 373 374 375 376 377 378 379 380 381 382 383 384 385 386 387 388 389 390 391 392 393 394 395 396 397 398 399 400 401 402 403 404 405 406 407 408 409 410 411 412 413 414 415 416 417 418 419 420 421 422 423 424 425 426 427 428 429 430 431 432 433 434 435 436 437 438 439 440 441 442 443 444 445 446 447 448 449 450 451 452 453 454 455 456 457 458 459 460 461 462 463 464 465 466 467 468 469 470 471 472 473 474 475 476 477 478 479 480 481 482 483 484 485 486 487 488 489 490 491 492 493 494 495 496 497 498 499 500 501 502 503 504 505 506 507 508 509 510 511 512 513 514 515 516 517 518 519 520 521 522 523 524 525 526 527 528 529 530 531 532 533 534 535 536 537 538 539 540 541 542 543 544 545 546 547 548 549 550 551 552 553 554 555 556 557 558 559 560 561 562 563 564 565 566 567 568 569 570 571 572 573 574 575 576 577 578 579 580 581 582 583 584 585 586 587 588 589 590 591 592 593 594 595 596 597 598 599 600 601 602 603 604 605 606 607 608 609 610 611 612 613 614 615 616 617 618 619 620 621 622 623 624 625 626 627 628 629 630 631 632 633 634 635 636 637 638 639 640 641 642 643 644 645 646 647 648 649 650 651 652 653 654 655 656 657 658 659 660 661 662 |
package com.zatackcoder.camera2test; import android.Manifest; import android.app.Activity; import android.content.Context; import android.content.pm.PackageManager; import android.content.res.Configuration; import android.graphics.ImageFormat; import android.graphics.Matrix; import android.graphics.Point; import android.graphics.RectF; import android.graphics.SurfaceTexture; import android.hardware.camera2.CameraAccessException; import android.hardware.camera2.CameraCaptureSession; import android.hardware.camera2.CameraCharacteristics; import android.hardware.camera2.CameraDevice; import android.hardware.camera2.CameraManager; import android.hardware.camera2.CameraMetadata; import android.hardware.camera2.CaptureRequest; import android.hardware.camera2.CaptureResult; import android.hardware.camera2.TotalCaptureResult; import android.hardware.camera2.params.StreamConfigurationMap; import android.media.Image; import android.media.ImageReader; import android.os.Build; import android.os.Environment; import android.os.Handler; import android.os.HandlerThread; import android.support.annotation.NonNull; import android.support.annotation.RequiresApi; import android.support.v4.content.ContextCompat; import android.util.Log; import android.util.Size; import android.util.SparseIntArray; import android.view.Surface; import android.view.TextureView; import android.widget.Toast; import java.io.File; import java.io.FileOutputStream; import java.io.IOException; import java.nio.ByteBuffer; import java.text.SimpleDateFormat; import java.util.ArrayList; import java.util.Arrays; import java.util.Collections; import java.util.Comparator; import java.util.Date; import java.util.List; import java.util.concurrent.Semaphore; import java.util.concurrent.TimeUnit; /** * Created by rajesh kumar sahanee on 2/9/17. */ @RequiresApi(api = Build.VERSION_CODES.LOLLIPOP) public class CameraControllerV2WithPreview { Activity activity; /** * Conversion from screen rotation to JPEG orientation. */ private static final SparseIntArray ORIENTATIONS = new SparseIntArray(); static { ORIENTATIONS.append(Surface.ROTATION_0, 90); ORIENTATIONS.append(Surface.ROTATION_90, 0); ORIENTATIONS.append(Surface.ROTATION_180, 270); ORIENTATIONS.append(Surface.ROTATION_270, 180); } private static final String TAG = "CCV2WithPreview"; private static final int STATE_PREVIEW = 0; private static final int STATE_WAITING_LOCK = 1; private static final int STATE_WAITING_PRECAPTURE = 2; private static final int STATE_WAITING_NON_PRECAPTURE = 3; private static final int STATE_PICTURE_TAKEN = 4; private static final int MAX_PREVIEW_WIDTH = 1920; private static final int MAX_PREVIEW_HEIGHT = 1080; private AutoFitTextureView textureView; private String mCameraId; private CameraCaptureSession mCaptureSession; private CameraDevice mCameraDevice; private Size mPreviewSize; private HandlerThread backgroundThread; private Handler backgroundHandler; private ImageReader imageReader; private File file; private CaptureRequest.Builder mPreviewRequestBuilder; private CaptureRequest mPreviewRequest; private int mState = STATE_PREVIEW; private Semaphore mCameraOpenCloseLock = new Semaphore(1); private boolean mFlashSupported; private int mSensorOrientation; public CameraControllerV2WithPreview(Activity activity, AutoFitTextureView textureView) { this.activity = activity; this.textureView = textureView; this.textureView.setSurfaceTextureListener(mSurfaceTextureListener); file = getOutputMediaFile(); } private final TextureView.SurfaceTextureListener mSurfaceTextureListener = new TextureView.SurfaceTextureListener() { @Override public void onSurfaceTextureAvailable(SurfaceTexture texture, int width, int height) { openCamera(width, height); } @Override public void onSurfaceTextureSizeChanged(SurfaceTexture texture, int width, int height) { configureTransform(width, height); } @Override public boolean onSurfaceTextureDestroyed(SurfaceTexture texture) { return true; } @Override public void onSurfaceTextureUpdated(SurfaceTexture texture) { } }; private final CameraDevice.StateCallback mStateCallback = new CameraDevice.StateCallback() { @Override public void onOpened(@NonNull CameraDevice cameraDevice) { // This method is called when the camera is opened. We start camera preview here. mCameraOpenCloseLock.release(); mCameraDevice = cameraDevice; createCameraPreviewSession(); } @Override public void onDisconnected(@NonNull CameraDevice cameraDevice) { mCameraOpenCloseLock.release(); cameraDevice.close(); mCameraDevice = null; } @Override public void onError(@NonNull CameraDevice cameraDevice, int error) { mCameraOpenCloseLock.release(); cameraDevice.close(); mCameraDevice = null; if(activity != null) { activity.finish(); } } }; private final ImageReader.OnImageAvailableListener mOnImageAvailableListener = new ImageReader.OnImageAvailableListener() { @Override public void onImageAvailable(ImageReader reader) { Log.d(TAG, "ImageAvailable"); backgroundHandler.post(new ImageSaver(reader.acquireNextImage(), file)); } }; private CameraCaptureSession.CaptureCallback mCaptureCallback = new CameraCaptureSession.CaptureCallback() { private void process(CaptureResult result) { switch (mState) { case STATE_PREVIEW: { // We have nothing to do when the camera preview is working normally. Log.d(TAG, "STATE_PREVIEW"); break; } case STATE_WAITING_LOCK: { Integer afState = result.get(CaptureResult.CONTROL_AF_STATE); if (afState == null) { captureStillPicture(); } else if (CaptureResult.CONTROL_AF_STATE_FOCUSED_LOCKED == afState || CaptureResult.CONTROL_AF_STATE_NOT_FOCUSED_LOCKED == afState) { // CONTROL_AE_STATE can be null on some devices Integer aeState = result.get(CaptureResult.CONTROL_AE_STATE); if (aeState == null || aeState == CaptureResult.CONTROL_AE_STATE_CONVERGED) { mState = STATE_PICTURE_TAKEN; captureStillPicture(); } else { runPrecaptureSequence(); } } Log.d(TAG, "STATE_WAITING_LOCK"); break; } case STATE_WAITING_PRECAPTURE: { // CONTROL_AE_STATE can be null on some devices Integer aeState = result.get(CaptureResult.CONTROL_AE_STATE); if (aeState == null || aeState == CaptureResult.CONTROL_AE_STATE_PRECAPTURE || aeState == CaptureRequest.CONTROL_AE_STATE_FLASH_REQUIRED) { mState = STATE_WAITING_NON_PRECAPTURE; } Log.d(TAG, "STATE_WAITING_PRECAPTURE"); break; } case STATE_WAITING_NON_PRECAPTURE: { // CONTROL_AE_STATE can be null on some devices Integer aeState = result.get(CaptureResult.CONTROL_AE_STATE); if (aeState == null || aeState != CaptureResult.CONTROL_AE_STATE_PRECAPTURE) { mState = STATE_PICTURE_TAKEN; captureStillPicture(); } Log.d(TAG, "STATE_WAITING_NON_PRECAPTURE"); break; } } } @Override public void onCaptureProgressed(@NonNull CameraCaptureSession session, @NonNull CaptureRequest request, @NonNull CaptureResult partialResult) { process(partialResult); } @Override public void onCaptureCompleted(@NonNull CameraCaptureSession session, @NonNull CaptureRequest request, @NonNull TotalCaptureResult result) { process(result); } }; private static Size chooseOptimalSize(Size[] choices, int textureViewWidth, int textureViewHeight, int maxWidth, int maxHeight, Size aspectRatio) { // Collect the supported resolutions that are at least as big as the preview Surface List<Size> bigEnough = new ArrayList<>(); // Collect the supported resolutions that are smaller than the preview Surface List<Size> notBigEnough = new ArrayList<>(); int w = aspectRatio.getWidth(); int h = aspectRatio.getHeight(); for (Size option : choices) { if (option.getWidth() <= maxWidth && option.getHeight() <= maxHeight && option.getHeight() == option.getWidth() * h / w) { if (option.getWidth() >= textureViewWidth && option.getHeight() >= textureViewHeight) { bigEnough.add(option); } else { notBigEnough.add(option); } } } // Pick the smallest of those big enough. If there is no one big enough, pick the // largest of those not big enough. if (bigEnough.size() > 0) { return Collections.min(bigEnough, new CompareSizesByArea()); } else if (notBigEnough.size() > 0) { return Collections.max(notBigEnough, new CompareSizesByArea()); } else { Log.e(TAG, "Couldn't find any suitable preview size"); return choices[0]; } } private void setUpCameraOutputs(int width, int height) { CameraManager manager = (CameraManager) activity.getSystemService(Context.CAMERA_SERVICE); try { for (String cameraId : manager.getCameraIdList()) { CameraCharacteristics characteristics = manager.getCameraCharacteristics(cameraId); // We don't use a front facing camera in this sample. Integer facing = characteristics.get(CameraCharacteristics.LENS_FACING); if (facing != null && facing == CameraCharacteristics.LENS_FACING_FRONT) { continue; } StreamConfigurationMap map = characteristics.get(CameraCharacteristics.SCALER_STREAM_CONFIGURATION_MAP); if (map == null) { continue; } // For still image captures, we use the largest available size. Size largest = Collections.max(Arrays.asList(map.getOutputSizes(ImageFormat.JPEG)), new CompareSizesByArea()); imageReader = ImageReader.newInstance(largest.getWidth(), largest.getHeight(), ImageFormat.JPEG, /*maxImages*/2); imageReader.setOnImageAvailableListener(mOnImageAvailableListener, backgroundHandler); // Find out if we need to swap dimension to get the preview size relative to sensor // coordinate. int displayRotation = activity.getWindowManager().getDefaultDisplay().getRotation();//getWindowManager().getDefaultDisplay().getRotation(); //noinspection ConstantConditions mSensorOrientation = characteristics.get(CameraCharacteristics.SENSOR_ORIENTATION); boolean swappedDimensions = false; switch (displayRotation) { case Surface.ROTATION_0: case Surface.ROTATION_180: if (mSensorOrientation == 90 || mSensorOrientation == 270) { swappedDimensions = true; } break; case Surface.ROTATION_90: case Surface.ROTATION_270: if (mSensorOrientation == 0 || mSensorOrientation == 180) { swappedDimensions = true; } break; default: Log.e(TAG, "Display rotation is invalid: " + displayRotation); } Point displaySize = new Point(); activity.getWindowManager().getDefaultDisplay().getSize(displaySize);//getWindowManager().getDefaultDisplay().getSize(displaySize); int rotatedPreviewWidth = width; int rotatedPreviewHeight = height; int maxPreviewWidth = displaySize.x; int maxPreviewHeight = displaySize.y; if (swappedDimensions) { rotatedPreviewWidth = height; rotatedPreviewHeight = width; maxPreviewWidth = displaySize.y; maxPreviewHeight = displaySize.x; } if (maxPreviewWidth > MAX_PREVIEW_WIDTH) { maxPreviewWidth = MAX_PREVIEW_WIDTH; } if (maxPreviewHeight > MAX_PREVIEW_HEIGHT) { maxPreviewHeight = MAX_PREVIEW_HEIGHT; } // Danger, W.R.! Attempting to use too large a preview size could exceed the camera // bus' bandwidth limitation, resulting in gorgeous previews but the storage of // garbage capture data. mPreviewSize = chooseOptimalSize(map.getOutputSizes(SurfaceTexture.class), rotatedPreviewWidth, rotatedPreviewHeight, maxPreviewWidth, maxPreviewHeight, largest); // We fit the aspect ratio of TextureView to the size of preview we picked. int orientation = activity.getResources().getConfiguration().orientation; if (orientation == Configuration.ORIENTATION_LANDSCAPE) { textureView.setAspectRatio(mPreviewSize.getWidth(), mPreviewSize.getHeight()); } else { textureView.setAspectRatio(mPreviewSize.getHeight(), mPreviewSize.getWidth()); } // Check if the flash is supported. Boolean available = characteristics.get(CameraCharacteristics.FLASH_INFO_AVAILABLE); mFlashSupported = available == null ? false : available; mCameraId = cameraId; return; } } catch (CameraAccessException e) { e.printStackTrace(); } catch (NullPointerException e) { // Currently an NPE is thrown when the Camera2API is used but not supported on the // device this code runs. e.printStackTrace(); } } public void openCamera(int width, int height) { if (ContextCompat.checkSelfPermission(activity, Manifest.permission.CAMERA) != PackageManager.PERMISSION_GRANTED) { return; } setUpCameraOutputs(width, height); configureTransform(width, height); CameraManager manager = (CameraManager) activity.getSystemService(Context.CAMERA_SERVICE); try { if (!mCameraOpenCloseLock.tryAcquire(2500, TimeUnit.MILLISECONDS)) { throw new RuntimeException("Time out waiting to lock camera opening."); } startBackgroundThread(); manager.openCamera(mCameraId, mStateCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } catch (InterruptedException e) { throw new RuntimeException("Interrupted while trying to lock camera opening.", e); } } public void closeCamera() { try { mCameraOpenCloseLock.acquire(); if (null != mCaptureSession) { mCaptureSession.close(); mCaptureSession = null; } if (null != mCameraDevice) { mCameraDevice.close(); mCameraDevice = null; } if (null != imageReader) { imageReader.close(); imageReader = null; } } catch (InterruptedException e) { throw new RuntimeException("Interrupted while trying to lock camera closing.", e); } finally { mCameraOpenCloseLock.release(); stopBackgroundThread(); } } private void startBackgroundThread() { backgroundThread = new HandlerThread("CameraBackground"); backgroundThread.start(); backgroundHandler = new Handler(backgroundThread.getLooper()); } private void stopBackgroundThread() { backgroundThread.quitSafely(); try { backgroundThread.join(); backgroundThread = null; backgroundHandler = null; } catch (InterruptedException e) { e.printStackTrace(); } } private void createCameraPreviewSession() { try { SurfaceTexture texture = textureView.getSurfaceTexture(); assert texture != null; // We configure the size of default buffer to be the size of camera preview we want. texture.setDefaultBufferSize(mPreviewSize.getWidth(), mPreviewSize.getHeight()); // This is the output Surface we need to start preview. Surface surface = new Surface(texture); // We set up a CaptureRequest.Builder with the output Surface. mPreviewRequestBuilder = mCameraDevice.createCaptureRequest(CameraDevice.TEMPLATE_PREVIEW); mPreviewRequestBuilder.addTarget(surface); // Here, we create a CameraCaptureSession for camera preview. mCameraDevice.createCaptureSession(Arrays.asList(surface, imageReader.getSurface()), new CameraCaptureSession.StateCallback() { @Override public void onConfigured(@NonNull CameraCaptureSession cameraCaptureSession) { // The camera is already closed if (null == mCameraDevice) { return; } // When the session is ready, we start displaying the preview. mCaptureSession = cameraCaptureSession; try { // Auto focus should be continuous for camera preview. mPreviewRequestBuilder.set(CaptureRequest.CONTROL_AF_MODE, CaptureRequest.CONTROL_AF_MODE_CONTINUOUS_PICTURE); // Flash is automatically enabled when necessary. setAutoFlash(mPreviewRequestBuilder); // Finally, we start displaying the camera preview. mPreviewRequest = mPreviewRequestBuilder.build(); mCaptureSession.setRepeatingRequest(mPreviewRequest, mCaptureCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } } @Override public void onConfigureFailed(@NonNull CameraCaptureSession cameraCaptureSession) { Log.d(TAG, "Configuration Failed"); } }, null ); } catch (CameraAccessException e) { e.printStackTrace(); } } private void configureTransform(int viewWidth, int viewHeight) { if (null == textureView || null == mPreviewSize) { return; } int rotation = activity.getWindowManager().getDefaultDisplay().getRotation();//getWindowManager().getDefaultDisplay().getRotation(); Matrix matrix = new Matrix(); RectF viewRect = new RectF(0, 0, viewWidth, viewHeight); RectF bufferRect = new RectF(0, 0, mPreviewSize.getHeight(), mPreviewSize.getWidth()); float centerX = viewRect.centerX(); float centerY = viewRect.centerY(); if (Surface.ROTATION_90 == rotation || Surface.ROTATION_270 == rotation) { bufferRect.offset(centerX - bufferRect.centerX(), centerY - bufferRect.centerY()); matrix.setRectToRect(viewRect, bufferRect, Matrix.ScaleToFit.FILL); float scale = Math.max( (float) viewHeight / mPreviewSize.getHeight(), (float) viewWidth / mPreviewSize.getWidth()); matrix.postScale(scale, scale, centerX, centerY); matrix.postRotate(90 * (rotation - 2), centerX, centerY); } else if (Surface.ROTATION_180 == rotation) { matrix.postRotate(180, centerX, centerY); } textureView.setTransform(matrix); } public void takePicture() { try { // This is how to tell the camera to lock focus. mPreviewRequestBuilder.set(CaptureRequest.CONTROL_AF_TRIGGER, CameraMetadata.CONTROL_AF_TRIGGER_START); // Tell #mCaptureCallback to wait for the lock. mState = STATE_WAITING_LOCK; mCaptureSession.capture(mPreviewRequestBuilder.build(), mCaptureCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } Toast.makeText(activity.getApplicationContext(), file.getAbsolutePath(), Toast.LENGTH_SHORT).show(); } private void runPrecaptureSequence() { try { // This is how to tell the camera to trigger. mPreviewRequestBuilder.set(CaptureRequest.CONTROL_AE_PRECAPTURE_TRIGGER, CaptureRequest.CONTROL_AE_PRECAPTURE_TRIGGER_START); // Tell #mCaptureCallback to wait for the precapture sequence to be set. mState = STATE_WAITING_PRECAPTURE; mCaptureSession.capture(mPreviewRequestBuilder.build(), mCaptureCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } } private void captureStillPicture() { try { if (null == mCameraDevice) { return; } // This is the CaptureRequest.Builder that we use to take a picture. final CaptureRequest.Builder captureBuilder = mCameraDevice.createCaptureRequest(CameraDevice.TEMPLATE_STILL_CAPTURE); captureBuilder.addTarget(imageReader.getSurface()); // Use the same AE and AF modes as the preview. captureBuilder.set(CaptureRequest.CONTROL_AF_MODE, CaptureRequest.CONTROL_AF_MODE_CONTINUOUS_PICTURE); setAutoFlash(captureBuilder); // Orientation int rotation = textureView.getDisplay().getRotation();//getWindowManager().getDefaultDisplay().getRotation(); captureBuilder.set(CaptureRequest.JPEG_ORIENTATION, getOrientation(rotation)); CameraCaptureSession.CaptureCallback CaptureCallback = new CameraCaptureSession.CaptureCallback() { @Override public void onCaptureCompleted(@NonNull CameraCaptureSession session, @NonNull CaptureRequest request, @NonNull TotalCaptureResult result) { Log.d(TAG, file.toString()); try { // Reset the auto-focus trigger mPreviewRequestBuilder.set(CaptureRequest.CONTROL_AF_TRIGGER, CameraMetadata.CONTROL_AF_TRIGGER_CANCEL); setAutoFlash(mPreviewRequestBuilder); mCaptureSession.capture(mPreviewRequestBuilder.build(), mCaptureCallback, backgroundHandler); // After this, the camera will go back to the normal state of preview. mState = STATE_PREVIEW; mCaptureSession.setRepeatingRequest(mPreviewRequest, mCaptureCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } } }; mCaptureSession.stopRepeating(); mCaptureSession.capture(captureBuilder.build(), CaptureCallback, null); } catch (CameraAccessException e) { e.printStackTrace(); } } private int getOrientation(int rotation) { // Sensor orientation is 90 for most devices, or 270 for some devices (eg. Nexus 5X) // We have to take that into account and rotate JPEG properly. // For devices with orientation of 90, we simply return our mapping from ORIENTATIONS. // For devices with orientation of 270, we need to rotate the JPEG 180 degrees. return (ORIENTATIONS.get(rotation) + mSensorOrientation + 270) % 360; } private void setAutoFlash(CaptureRequest.Builder requestBuilder) { if (mFlashSupported) { requestBuilder.set(CaptureRequest.CONTROL_AE_MODE, CaptureRequest.CONTROL_AE_MODE_ON_AUTO_FLASH); } } private static class ImageSaver implements Runnable { /** * The JPEG image */ private final Image mImage; /** * The file we save the image into. */ private final File mFile; public ImageSaver(Image image, File file) { mImage = image; mFile = file; } @Override public void run() { ByteBuffer buffer = mImage.getPlanes()[0].getBuffer(); byte[] bytes = new byte[buffer.remaining()]; buffer.get(bytes); FileOutputStream output = null; try { output = new FileOutputStream(mFile); output.write(bytes); } catch (IOException e) { e.printStackTrace(); } finally { mImage.close(); if (null != output) { try { output.close(); } catch (IOException e) { e.printStackTrace(); } } } } } static class CompareSizesByArea implements Comparator<Size> { @Override public int compare(Size lhs, Size rhs) { // We cast here to ensure the multiplications won't overflow return Long.signum((long) lhs.getWidth() * lhs.getHeight() - (long) rhs.getWidth() * rhs.getHeight()); } } private File getOutputMediaFile() { // To be safe, you should check that the SDCard is mounted // using Environment.getExternalStorageState() before doing this. File mediaStorageDir = new File(Environment.getExternalStoragePublicDirectory(Environment.DIRECTORY_PICTURES), "Camera2Test"); // This location works best if you want the created images to be shared // between applications and persist after your app has been uninstalled. // Create the storage directory if it does not exist if (!mediaStorageDir.exists()) { if (!mediaStorageDir.mkdirs()) { return null; } } // Create a media file name String timeStamp = new SimpleDateFormat("yyyyMMdd_HHmmss").format(new Date()); File mediaFile; mediaFile = new File(mediaStorageDir.getPath() + File.separator + "IMG_" + timeStamp + ".jpg"); return mediaFile; } } |
CameraControllerV2WithoutPreview.java
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 |
package com.zatackcoder.camera2test; import android.Manifest; import android.content.Context; import android.content.pm.PackageManager; import android.graphics.ImageFormat; import android.hardware.camera2.CameraAccessException; import android.hardware.camera2.CameraCaptureSession; import android.hardware.camera2.CameraCharacteristics; import android.hardware.camera2.CameraDevice; import android.hardware.camera2.CameraManager; import android.hardware.camera2.CaptureRequest; import android.hardware.camera2.TotalCaptureResult; import android.hardware.camera2.params.StreamConfigurationMap; import android.media.Image; import android.media.ImageReader; import android.os.Build; import android.os.Environment; import android.os.Handler; import android.os.HandlerThread; import android.support.annotation.NonNull; import android.support.annotation.RequiresApi; import android.support.v4.content.ContextCompat; import android.util.Log; import android.util.Size; import android.widget.Toast; import java.io.File; import java.io.FileOutputStream; import java.io.IOException; import java.nio.ByteBuffer; import java.text.SimpleDateFormat; import java.util.Arrays; import java.util.Collections; import java.util.Comparator; import java.util.Date; import java.util.concurrent.Semaphore; import java.util.concurrent.TimeUnit; /** * Created by rajesh kumar sahanee on 2/9/17. */ @RequiresApi(api = Build.VERSION_CODES.LOLLIPOP) public class CameraControllerV2WithoutPreview { Context context; private static final String TAG = "CCV2WithoutPreview"; private String mCameraId; private CameraCaptureSession mCaptureSession; private CameraDevice mCameraDevice; private HandlerThread backgroundThread; private Handler backgroundHandler; private ImageReader imageReader; private File file; private Semaphore mCameraOpenCloseLock = new Semaphore(1); public CameraControllerV2WithoutPreview(Context context) { this.context = context; } public void openCamera() { if (ContextCompat.checkSelfPermission(context, Manifest.permission.CAMERA) != PackageManager.PERMISSION_GRANTED) { return; } setUpCameraOutputs(); CameraManager manager = (CameraManager) context.getSystemService(Context.CAMERA_SERVICE); try { if (!mCameraOpenCloseLock.tryAcquire(2500, TimeUnit.MILLISECONDS)) { throw new RuntimeException("Time out waiting to lock camera opening."); } startBackgroundThread(); manager.openCamera(mCameraId, mStateCallback, backgroundHandler); } catch (CameraAccessException e) { e.printStackTrace(); } catch (InterruptedException e) { throw new RuntimeException("Interrupted while trying to lock camera opening.", e); } } private void setUpCameraOutputs() { CameraManager manager = (CameraManager) context.getSystemService(Context.CAMERA_SERVICE); try { for (String cameraId : manager.getCameraIdList()) { CameraCharacteristics characteristics = manager.getCameraCharacteristics(cameraId); // We don't use a front facing camera in this sample. Integer facing = characteristics.get(CameraCharacteristics.LENS_FACING); if (facing != null && facing == CameraCharacteristics.LENS_FACING_FRONT) { continue; } StreamConfigurationMap map = characteristics.get(CameraCharacteristics.SCALER_STREAM_CONFIGURATION_MAP); if (map == null) { continue; } // For still image captures, we use the largest available size. Size largest = Collections.max(Arrays.asList(map.getOutputSizes(ImageFormat.JPEG)), new CompareSizesByArea()); imageReader = ImageReader.newInstance(largest.getWidth(), largest.getHeight(), ImageFormat.JPEG, /*maxImages*/2); imageReader.setOnImageAvailableListener(mOnImageAvailableListener, backgroundHandler); mCameraId = cameraId; return; } } catch (CameraAccessException e) { e.printStackTrace(); } catch (NullPointerException e) { // Currently an NPE is thrown when the Camera2API is used but not supported on the // device this code runs. e.printStackTrace(); } } private final CameraDevice.StateCallback mStateCallback = new CameraDevice.StateCallback() { @Override public void onOpened(@NonNull CameraDevice cameraDevice) { // This method is called when the camera is opened. We start camera preview here. mCameraOpenCloseLock.release(); mCameraDevice = cameraDevice; createCameraCaptureSession(); } @Override public void onDisconnected(@NonNull CameraDevice cameraDevice) { mCameraOpenCloseLock.release(); cameraDevice.close(); mCameraDevice = null; } @Override public void onError(@NonNull CameraDevice cameraDevice, int error) { mCameraOpenCloseLock.release(); cameraDevice.close(); mCameraDevice = null; } }; private final ImageReader.OnImageAvailableListener mOnImageAvailableListener = new ImageReader.OnImageAvailableListener() { @Override public void onImageAvailable(ImageReader reader) { Log.d(TAG, "ImageAvailable"); backgroundHandler.post(new ImageSaver(reader.acquireNextImage(), file)); } }; public void closeCamera() { try { mCameraOpenCloseLock.acquire(); if (null != mCaptureSession) { mCaptureSession.close(); mCaptureSession = null; } if (null != mCameraDevice) { mCameraDevice.close(); mCameraDevice = null; } if (null != imageReader) { imageReader.close(); imageReader = null; } } catch (InterruptedException e) { throw new RuntimeException("Interrupted while trying to lock camera closing.", e); } finally { mCameraOpenCloseLock.release(); stopBackgroundThread(); } } private void startBackgroundThread() { backgroundThread = new HandlerThread("CameraBackground"); backgroundThread.start(); backgroundHandler = new Handler(backgroundThread.getLooper()); } private void stopBackgroundThread() { backgroundThread.quitSafely(); try { backgroundThread.join(); backgroundThread = null; backgroundHandler = null; } catch (InterruptedException e) { e.printStackTrace(); } } private void createCameraCaptureSession() { try { // Here, we create a CameraCaptureSession for camera preview. mCameraDevice.createCaptureSession(Arrays.asList(imageReader.getSurface()), new CameraCaptureSession.StateCallback() { @Override public void onConfigured(@NonNull CameraCaptureSession cameraCaptureSession) { // The camera is already closed if (null == mCameraDevice) { return; } // When the session is ready, we start displaying the preview. mCaptureSession = cameraCaptureSession; } @Override public void onConfigureFailed(@NonNull CameraCaptureSession cameraCaptureSession) { Log.d(TAG, "Configuration Failed"); } }, null ); } catch (CameraAccessException e) { e.printStackTrace(); } } public void takePicture() { file = getOutputMediaFile(); try { if (null == mCameraDevice) { return; } // This is the CaptureRequest.Builder that we use to take a picture. final CaptureRequest.Builder captureBuilder = mCameraDevice.createCaptureRequest(CameraDevice.TEMPLATE_STILL_CAPTURE); captureBuilder.addTarget(imageReader.getSurface()); // Use the same AE and AF modes as the preview. captureBuilder.set(CaptureRequest.CONTROL_AF_MODE, CaptureRequest.CONTROL_AF_MODE_CONTINUOUS_PICTURE); CameraCaptureSession.CaptureCallback CaptureCallback = new CameraCaptureSession.CaptureCallback() { @Override public void onCaptureCompleted(@NonNull CameraCaptureSession session, @NonNull CaptureRequest request, @NonNull TotalCaptureResult result) { Log.d(TAG, file.toString()); } }; mCaptureSession.stopRepeating(); mCaptureSession.capture(captureBuilder.build(), CaptureCallback, null); } catch (CameraAccessException e) { e.printStackTrace(); } Toast.makeText(context, file.getAbsolutePath(), Toast.LENGTH_SHORT).show(); } private static class ImageSaver implements Runnable { /** * The JPEG image */ private final Image mImage; /** * The file we save the image into. */ private final File mFile; public ImageSaver(Image image, File file) { mImage = image; mFile = file; } @Override public void run() { ByteBuffer buffer = mImage.getPlanes()[0].getBuffer(); byte[] bytes = new byte[buffer.remaining()]; buffer.get(bytes); FileOutputStream output = null; try { output = new FileOutputStream(mFile); output.write(bytes); } catch (IOException e) { e.printStackTrace(); } finally { mImage.close(); if (null != output) { try { output.close(); } catch (IOException e) { e.printStackTrace(); } } } } } static class CompareSizesByArea implements Comparator<Size> { @Override public int compare(Size lhs, Size rhs) { // We cast here to ensure the multiplications won't overflow return Long.signum((long) lhs.getWidth() * lhs.getHeight() - (long) rhs.getWidth() * rhs.getHeight()); } } private File getOutputMediaFile() { // To be safe, you should check that the SDCard is mounted // using Environment.getExternalStorageState() before doing this. File mediaStorageDir = new File(Environment.getExternalStoragePublicDirectory(Environment.DIRECTORY_PICTURES), "Camera2Test"); // This location works best if you want the created images to be shared // between applications and persist after your app has been uninstalled. // Create the storage directory if it does not exist if (!mediaStorageDir.exists()) { if (!mediaStorageDir.mkdirs()) { return null; } } // Create a media file name String timeStamp = new SimpleDateFormat("yyyyMMdd_HHmmss").format(new Date()); File mediaFile; mediaFile = new File(mediaStorageDir.getPath() + File.separator + "IMG_" + timeStamp + ".jpg"); return mediaFile; } } |
AutoFitTextureView.java
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 |
package com.zatackcoder.camera2test; import android.content.Context; import android.util.AttributeSet; import android.view.TextureView; /** * Created by rajesh on 6/9/17. */ public class AutoFitTextureView extends TextureView { private int mRatioWidth = 0; private int mRatioHeight = 0; public AutoFitTextureView(Context context) { this(context, null); } public AutoFitTextureView(Context context, AttributeSet attrs) { this(context, attrs, 0); } public AutoFitTextureView(Context context, AttributeSet attrs, int defStyle) { super(context, attrs, defStyle); } /** * Sets the aspect ratio for this view. The size of the view will be measured based on the ratio * calculated from the parameters. Note that the actual sizes of parameters don't matter, that * is, calling setAspectRatio(2, 3) and setAspectRatio(4, 6) make the same result. * * @param width Relative horizontal size * @param height Relative vertical size */ public void setAspectRatio(int width, int height) { if (width < 0 || height < 0) { throw new IllegalArgumentException("Size cannot be negative."); } mRatioWidth = width; mRatioHeight = height; requestLayout(); } @Override protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { super.onMeasure(widthMeasureSpec, heightMeasureSpec); int width = MeasureSpec.getSize(widthMeasureSpec); int height = MeasureSpec.getSize(heightMeasureSpec); if (0 == mRatioWidth || 0 == mRatioHeight) { setMeasuredDimension(width, height); } else { if (width < height * mRatioWidth / mRatioHeight) { setMeasuredDimension(width, width * mRatioHeight / mRatioWidth); } else { setMeasuredDimension(height * mRatioWidth / mRatioHeight, height); } } } } |
MainActivity.java
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 |
package com.zatackcoder.camera2test; import android.Manifest; import android.content.Intent; import android.content.pm.PackageManager; import android.os.Build; import android.os.Bundle; import android.support.annotation.RequiresApi; import android.support.v4.app.ActivityCompat; import android.support.v7.app.AppCompatActivity; import android.support.v7.widget.Toolbar; import android.view.View; import android.widget.Switch; import android.widget.Toast; @RequiresApi(api = Build.VERSION_CODES.LOLLIPOP) public class MainActivity extends AppCompatActivity implements ActivityCompat.OnRequestPermissionsResultCallback { CameraControllerV2WithPreview ccv2WithPreview; CameraControllerV2WithoutPreview ccv2WithoutPreview; AutoFitTextureView textureView; Switch startstoppreview; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar); setSupportActionBar(toolbar); final Intent intent = getIntent(); boolean showpreview = intent.getBooleanExtra("showpreview", false); textureView = (AutoFitTextureView)findViewById(R.id.textureview); startstoppreview = (Switch) findViewById(R.id.startstoppreview); if(showpreview) { ccv2WithPreview = new CameraControllerV2WithPreview(MainActivity.this, textureView); startstoppreview.setChecked(true); } else { ccv2WithoutPreview = new CameraControllerV2WithoutPreview(getApplicationContext()); startstoppreview.setChecked(false); } startstoppreview.setOnClickListener(new View.OnClickListener(){ @Override public void onClick(View view) { if(startstoppreview.isChecked()) { intent.putExtra("showpreview", true); finish(); startActivity(intent); } else { intent.putExtra("showpreview", false); finish(); startActivity(intent); } } }); findViewById(R.id.getpicture).setOnClickListener(new View.OnClickListener(){ @Override public void onClick(View view) { if(startstoppreview.isChecked() && ccv2WithPreview != null) { ccv2WithPreview.takePicture(); } else if(ccv2WithoutPreview != null){ ccv2WithoutPreview.openCamera(); try { Thread.sleep(20); } catch (InterruptedException e) {} ccv2WithoutPreview.takePicture(); } Toast.makeText(getApplicationContext(), "Picture Clicked", Toast.LENGTH_SHORT).show(); } }); getPermissions(); } @Override protected void onDestroy() { super.onDestroy(); // if(ccv2WithPreview != null) { // ccv2WithPreview.closeCamera(); // } // if(ccv2WithoutPreview != null) { // ccv2WithoutPreview.closeCamera(); // } } private void getPermissions(){ if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) { if(checkSelfPermission(Manifest.permission.CAMERA) != PackageManager.PERMISSION_GRANTED || checkSelfPermission(Manifest.permission.WRITE_EXTERNAL_STORAGE) != PackageManager.PERMISSION_GRANTED){ //Requesting permission. ActivityCompat.requestPermissions(this, new String[]{Manifest.permission.CAMERA, Manifest.permission.WRITE_EXTERNAL_STORAGE}, 1); } } } @Override //Override from ActivityCompat.OnRequestPermissionsResultCallback Interface public void onRequestPermissionsResult(int requestCode, String[] permissions, int[] grantResults) { switch (requestCode) { case 1: { // If request is cancelled, the result arrays are empty. if (grantResults.length > 0 && grantResults[0] == PackageManager.PERMISSION_GRANTED) { // permission granted } return; } } } } |
activity_main.xml
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 |
<?xml version="1.0" encoding="utf-8"?> <android.support.design.widget.CoordinatorLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" tools:context="com.zatackcoder.camera2test.MainActivity"> <android.support.design.widget.AppBarLayout android:layout_width="match_parent" android:layout_height="wrap_content" android:theme="@style/AppTheme.AppBarOverlay"> <android.support.v7.widget.Toolbar android:id="@+id/toolbar" android:layout_width="match_parent" android:layout_height="?attr/actionBarSize" android:background="?attr/colorPrimary" app:popupTheme="@style/AppTheme.PopupOverlay" /> </android.support.design.widget.AppBarLayout> <include layout="@layout/content_main" /> </android.support.design.widget.CoordinatorLayout> |
content_main.xml
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 |
<?xml version="1.0" encoding="utf-8"?> <android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" app:layout_behavior="@string/appbar_scrolling_view_behavior" tools:context="com.zatackcoder.camera2test.MainActivity" tools:showIn="@layout/activity_main"> <RelativeLayout android:layout_width="0dp" android:layout_height="0dp" android:orientation="vertical" app:layout_constraintBottom_toBottomOf="parent" app:layout_constraintLeft_toLeftOf="parent" app:layout_constraintRight_toRightOf="parent" app:layout_constraintTop_toTopOf="parent" android:layout_margin="5dp"> <com.zatackcoder.camera2test.AutoFitTextureView android:id="@+id/textureview" android:layout_width="match_parent" android:layout_height="wrap_content" /> <LinearLayout android:layout_width="match_parent" android:layout_height="wrap_content" android:layout_alignParentBottom="true" android:orientation="vertical"> <Switch android:id="@+id/startstoppreview" android:layout_width="match_parent" android:layout_height="wrap_content" android:text="Start Preview" /> <Button android:id="@+id/getpicture" android:layout_width="match_parent" android:layout_height="wrap_content" android:text="getPicture" /> </LinearLayout> </RelativeLayout> </android.support.constraint.ConstraintLayout> |
Output
Android Studio Project Download
Android Camera 2 Api Example
1 file(s) 23.96 MB
Thanks
Please share if you like and if you have any question you can ask in comment
